 2027年～2037年の世界のコパッケージド・オプティクス市場The Global Co-Packaged Optics Market 2027-2037 コパッケージド・オプティクス（CPO）は、ここ数十年間で光インターコネクトに対する最も根本的な再考を表しており、光エンジンをスイッチのフェースプレートから、スイッチやアクセラレータのシリコンのす... もっと見る
出版社
Future Markets, inc.
フューチャーマーケッツインク 出版年月
2026年6月10日
電子版価格
納期
PDF：3-5営業日程度
ページ数
470
図表数
290
言語
英語
サマリー コパッケージド・オプティクス（CPO）は、ここ数十年間で光インターコネクトに対する最も根本的な再考を表しており、光エンジンをスイッチのフェースプレートから、スイッチやアクセラレータのシリコンのすぐ隣の位置へと移動させるものです。 高速電気経路をセンチメートル単位からミリメートル単位へと短縮することで、CPOは「相互接続の壁」を克服します。この「相互接続の壁」とは、スイッチではおよそ2年ごとに2倍になり、モデルパラメータではさらに急速に増加するAIの帯域幅需要と、レーンあたりの光速度（約4年ごとに2倍になる程度）との間に広がるギャップを指します。 この技術は、プラグイン式トランシーバーに比べて電力効率が大幅に改善され、レイテンシも大幅に低減されるため、AIデータセンターが抱える電力、密度、およびビットあたりのコストという制約に対処します。 市場は、スケールアウト型 CPO（ネットワークスイッチの光エンジン）とスケールアップ型 CPO（GPU および AI アクセラレータの光 I/O）に分かれており、この 10 年の終わり頃にはスケールアップ型がスケールアウト型を追い抜き、その後は主要なセグメントとなる見込みです。 採用は、プラグイン式モジュールが物理的および経済的な限界に達している最高帯域幅のネットワークスイッチから始まり、次世代GPUプラットフォームの普及に伴い、AIアクセラレータの光I/Oへと拡大していく。 最近の動向は決定的なものとなっている。NVIDIAは、Coherent社およびLumentum社への大規模な戦略的投資を通じてレーザーのサプライチェーンへの参入を確約し、Quantum-XおよびSpectrum-X Photonics CPOスイッチの量産化へと移行した。 TSMCはCOUPEロードマップを固めた。これは2026年に量産開始予定の200 Gbpsマイクロリング変調器であり、2030年までに4 Tbps/mmの帯域幅密度を目標としている。一方、GlobalFoundriesはOCI-MSAに準拠したSCALEプラットフォームを発表し、8λおよび16λの実証に成功した。 Ayar LabsはシリーズEの資金調達を経てNVIDIAのNVLink Fusionエコシステムに参画し、MarvellはCelestial AIの買収を完了し、FabrinetはRaytek Semiconductorに出資した。OCI-MSA（AMD、Broadcom、Meta、Microsoft、NVIDIA、OpenAI）が、事実上のスケールアップ用相互接続規格として台頭した。 この勢いに対抗するかのように、NVIDIAのCPOの大規模生産は、システムエンジニアリング上の理由（保守性、信頼性、製造・テスト歩留まり）により、2028年から2029年へと延期される可能性がある。これにより、ニアパッケージ光学（NPO）が現実的な中間手段として注目を集め、光関連銘柄全体で急激な売り圧力が生じた。 年間生産台数を約100万台から数千万台へと拡大するための試験および製造のスケールアップが、現在、最大の制約要因と見なされており、自動化された電気・光のデュアルドメイン試験セルと標準化された光コネクタが求められている。 CPOの方向性は定まったというのがコンセンサスであり、その採用ペースが中心的な変数となっている。これは、歩留まりの成熟度、実環境での信頼性、そしてハイパースケーラーによる認定が、スケールアップおよびスケールアウトネットワーク全体での量産展開へと転換する速度によって左右される。 『2027-2037年 グローバル・コパッケージド・オプティクス市場』は、AIデータセンター、ハイパースケール、およびハイパフォーマンス・コンピューティング（HPC）アプリケーションにおけるコパッケージド・オプティクスに関する包括的な市場および技術評価です。 銅線やプラグイン式光モジュールが物理的および経済的な根本的な限界に達する中、CPOはスケールアップおよびスケールアウト型AIネットワークの基盤となる相互接続技術として台頭しています。本レポートは、この移行を乗り切るために必要なデータ、技術分析、および競合情報を提供します。 本レポートでは、2026年から2037年までの市場を、用途別（スイッチ用CPOおよびXPU用光I/O）、スイッチ帯域幅世代別（51.2T、102.4T、 204.8T+）、集積技術（2D、2.5Dシリコン／有機／ガラス、3Dマイクロバンプおよびハイブリッドボンディング）、コンポーネント、および地域（北米、アジア太平洋、欧州、その他の地域）ごとに市場を分析しています。 本レポートには、確率評価を伴う強気・中立・弱気の各シナリオ、出荷台数および価格の推移、プラグイン型デバイスとのコストパリティ分析、総所有コスト（TCO）のモデリングが含まれています。 技術面では、本レポートはフォトニック集積回路およびシリコンフォトニクス、光エンジンアーキテクチャ、遅延・消費電力・データレートにおけるCPOの利点、レーンあたり200Gへの移行、変調器材料（シリコンマイクロリング、TFLN、BTO、リン化インジウム）、 波長分割多重（WDM）および「ビーチフロント」と呼ばれるファイバー本数制約；チャネル数のスケーリング；エンドツーエンドの光リンク予算；先進パッケージング（シリコン、有機、ガラスインターポーザー、TSV、ハイブリッドボンディング）； EIC/PIC統合；レーザー光源および外部レーザーアーキテクチャ；ファイバーアレイユニットおよび着脱式コネクタ；規格（OIF、OCI-MSA、UCIe、XPO、Open CPX）；ならびにCPOのテストおよび製造スケールアップ。 また、最近の業界再編やNVIDIAのサプライチェーンへの投資を含め、産業エコシステム全体とサプライチェーンについても分析している。 レポートの内容は以下の通りです：
Summary
Co-packaged optics (CPO) represents the most fundamental rethinking of optical interconnect in decades, moving the optical engine from the switch faceplate to a position immediately adjacent to the switch or accelerator silicon. By collapsing the high-speed electrical path from centimetres to millimetres, CPO overcomes the "interconnect wall" — the widening gap between AI bandwidth demand, which doubles roughly every two years at the switch and far faster for model parameters, and per-lane optical speed, which doubles only about every four years. The technology delivers materially better power efficiency and substantially lower latency than pluggable transceivers, addressing the binding power, density and cost-per-bit constraints of AI data centres.
The market divides into scale-out CPO (network-switch optical engines) and scale-up CPO (GPU and AI-accelerator optical I/O), with scale-up overtaking scale-out toward the end of the decade and becoming the dominant segment thereafter. Adoption begins in the highest-bandwidth network switches, where pluggable modules hit physical and economic limits, and extends into AI-accelerator optical I/O as next-generation GPU platforms ramp.
Recent developments have been decisive. NVIDIA committed to the laser supply chain with major strategic investments in Coherent and Lumentum, and moved its Quantum-X and Spectrum-X Photonics CPO switches toward production. TSMC firmed its COUPE roadmap — a 200 Gbps micro-ring modulator in production in 2026, targeting 4 Tbps/mm bandwidth density by 2030 — while GlobalFoundries launched the OCI-MSA-aligned SCALE platform with 8λ and 16λ demonstrated. Ayar Labs joined NVIDIA's NVLink Fusion ecosystem after a Series E raise; Marvell completed its Celestial AI acquisition; and Fabrinet invested in Raytek Semiconductor. The OCI-MSA (AMD, Broadcom, Meta, Microsoft, NVIDIA, OpenAI) emerged as the de facto scale-up interconnect standard.
Counterbalancing the momentum, large-scale NVIDIA CPO production could slip to 2028–2029 on systems-engineering grounds — serviceability, reliability and manufacturing-test yield — elevating near-package optics (NPO) as a pragmatic intermediate and triggering a sharp sell-off across optical equities. Test and manufacturing scale-up, from roughly one million to tens of millions of units annually, is now seen as the binding constraint, demanding automated, dual-domain electrical-and-optical test cells and standardised optical connectors. The consensus is that CPO's direction is settled; its rate of adoption is the central variable, shaped by yield maturation, field reliability and the pace at which hyperscaler qualification converts into volume deployment across scale-up and scale-out networks.
The Global Co-Packaged Optics Market 2027-2037 is a comprehensive market and technology assessment of co-packaged optics across AI data-centre, hyperscale and high-performance-computing applications. As copper and pluggable optics reach fundamental physical and economic limits, CPO is emerging as the foundational interconnect technology for scale-up and scale-out AI networks. This report provides the data, technology analysis and competitive intelligence needed to navigate the transition.
The report assesses the market from 2026 through 2037, segmented by application (switch CPO and XPU optical I/O), by switch bandwidth generation (51.2T, 102.4T, 204.8T+), by integration technology (2D, 2.5D silicon/organic/glass, 3D micro-bump and hybrid bonding), by component, and by region (North America, Asia-Pacific, Europe, Rest of World). It includes bull, base and bear scenarios with probability assessments, unit-volume and pricing trajectories, cost-parity analysis versus pluggables, and total-cost-of-ownership modelling.
Technically, the report covers photonic integrated circuits and silicon photonics; optical-engine architecture; the benefits of CPO in latency, power and data rate; the 200G-per-lane transition; modulator materials (silicon micro-ring, TFLN, BTO, indium phosphide); wavelength-division multiplexing and the "beachfront" fibre-count constraint; channel-count scaling; the end-to-end optical link budget; advanced packaging (silicon, organic and glass interposers, TSV, hybrid bonding); EIC/PIC integration; laser sources and external-laser architectures; fibre array units and detachable connectors; standards (OIF, OCI-MSA, UCIe, XPO, Open CPX); and CPO test and manufacturing scale-up. It also analyses the full industrial ecosystem and supply chain, including recent consolidation and NVIDIA's supply-chain investments.
Report contents include:
Table of Contents
