メモリとストレージ技術の世界市場 2026-2036年

メモリとストレージ技術の世界市場 2026-2036年


The Global Memory and Storage Technology Market 2026-2036

世界のメモリ・ストレージ技術市場は、人工知能、ハイパフォーマンス・コンピューティング、次世代データインフラからの爆発的な需要に牽引され、2036年には4,000億ドルを超えると予測され、大幅な... もっと見る





出版社 出版年月 電子版価格 納期 ページ数 図表数 言語
Future Markets, inc.
フューチャーマーケッツインク
2025年6月30日 GBP1,200
シングルユーザーライセンス
ライセンス・価格情報
注文方法はこちら
PDF:3-5営業日程度 379 259 英語



サマリー

世界のメモリ・ストレージ技術市場は、人工知能、ハイパフォーマンス・コンピューティング、次世代データインフラからの爆発的な需要に牽引され、2036年には4,000億ドルを超えると予測され、大幅な拡大が見込まれている。2022~2023年の深刻な景気後退から回復した後、業界は2025年に2,000億ドルを超える記録的な収益を達成し、AIワークロードによって根本的に形を変えた持続的な成長軌道の幕開けとなった。

高帯域幅メモリー(HBM)は、市場で最もダイナミックなセグメントとして浮上している。AIのトレーニングや推論アプリケーションはかつてないメモリ帯域幅を要求するため、DRAM市場全体に占めるHBMのシェアは10年後までに50%に達すると予想される。サムスン、SKハイニックス、マイクロンをはじめとする大手メーカーは、HBM3Eの生産を積極的に拡大しており、次世代HBM4テクノロジーはさらなる性能向上を約束しています。NANDフラッシュ技術は、3Dスケーリングの革新を通じて進化を続けており、各メーカーは先進的なCMOSボンデッドアレイ(CBA)アーキテクチャを使用して300層を超えようとしています。YMTCのXtacking 4.0技術や業界のペンタレベルセル(PLC)ストレージへの移行は、この分野の絶え間ない密度向上を示している。一方、磁気抵抗RAM(MRAM)、抵抗RAM(ReRAM)、強誘電体RAM(FeRAM)などの新興メモリー技術は、特に組み込みアプリケーションやエッジ・コンピューティング・デバイスで商業的な牽引力を増している。

中国のメモリーメーカーは、YMTCが294層の3D NAND生産を達成し、CXMTが国産DDR5モジュールの発売に成功するなど、競争力学を根本的に変えつつある。中国のメモリー市場シェアは消費者向け、企業向けともに拡大を続けており、世界のトップ企業はプレミアム製品の開発と先端技術の採用を加速する必要に迫られている。米国の輸出規制が続いているにもかかわらず、JHICCは生産能力を増強し、SwaySure Technologyのような新規参入企業は国内サプライチェーンを強化するなど、中国企業は目覚ましい技術進歩を示している。

データセンターとクラウド・インフラは最大の成長ドライバーであり、AI/MLワークロードに最適化された高度化するストレージ・ソリューションを消費している。ハイパースケール環境における従来のHDDに対するQLC SSDの経済的優位性は、ストレージ階層を再構築しており、10PBのQLC導入は、従来の階層型ストレージ・アーキテクチャに比べて3,000万ドル以上のコスト削減を実現している。エッジコンピューティングと自動車アプリケーションは、自律走行車とIoTデバイスが高性能で信頼性の高いメモリソリューションを必要とするため、さらなる需要ベクトルを生み出しています。従来のプレーナー技術が物理的な限界に近づいているため、業界はスケーリングの課題に直面しています。3D DRAM アーキテクチャ、縦型トランジスタ設計、および新しいセル構造は、2030 年以降の重要な技術的道筋となります。ウエハー・ツー・ウエハー・ボンディングやチップレット・インテグレーションなどの先進的なパッケージング技術革新は、製造の複雑さを管理しながら、継続的な性能向上を可能にします。

エネルギー効率の高い設計や循環型経済への取り組みに投資するメーカーを中心に、環境の持続可能性がますます技術開発に影響を及ぼすようになっている。地政学的緊張は引き続きグローバル・サプライチェーンを再構築し、長期的な市場ダイナミクスに影響を与える地域化傾向と技術移転規制を促進する。2036年までのメモリー・ストレージ技術市場は、AIの普及、技術的ブレークスルーの達成、進化する競争環境に牽引される根本的な変革を意味する。成功のためには、複雑なスケーリングの課題を克服しながら、あらゆる市場セグメントにわたる次世代コンピューティング・アプリケーションからの爆発的な需要を活用する必要があります。

世界のメモリとストレージ技術市場 2026-2036」は、急速に進化するメモリとストレージの展望を洞察し、2036年までの業界の変革をナビゲートする技術リーダー、投資家、戦略的意思決定者に重要な分析を提供します。
レポート内容は以下の通りです:


市場予測と技術セグメンテーション

  • 2026年~2036年の世界市場収益予測(技術別、用途別、地域別の詳細な内訳付き) 高帯域幅メモリ(HBM)の成長軌跡、DDRの進化、モバイルメモリの動向を含むDRAM市場分析
  • 企業向け、コンシューマー向け、QLCやSSDなどの新興セル技術を含むNANDフラッシュとSSDの市場予測、QLCおよびPLCの開発を含む、企業向けおよび新興のセル技術
  • エネルギーアシスト記録技術(HAMR/MAMR)の採用スケジュールを含む、ハードディスクドライブ市場の進化
  • 組み込み型およびスタンドアロン型アプリケーションにおける、MRAM、ReRAM、FeRAM、PCMの新興メモリ技術市場サイジング

先端技術分析とロードマップ:

  • プレーナースケーリングの課題から3Dアーキテクチャ開発までの詳細なDRAM技術の進展
  • CMOSボンディングおよび垂直トランジスタ実装を含む高度集積技術
  • 3Dスタッキング、熱管理、およびプロセッサ統合戦略をカバーするHBM技術の進化
  • CBAおよびXtacking技術実装による300層を超えるNANDフラッシュのスケーリング分析
  • 性能ベンチマークおよび商業化スケジュールを含む包括的な新興メモリ技術の比較

サプライチェーンおよび製造インテリジェンス:

  • 設備投資動向を含む技術別および地域別のグローバル製造能力分析
  • 技術ノードの移行戦略と歩留まり学習曲線の最適化
  • 重要な製造ツールと材料を網羅する装置サプライヤー分析
  • 中国のメモリ産業の発展と貿易制限の影響を含む地域市場ダイナミクス

アプリケーション別市場分析:

  • LLMインフラのスケーリングを含むAIと機械学習メモリ要件
  • QLC SSD経済分析によるデータセンターとクラウドストレージの進化
  • ADASレベルと自律走行車ストレージアーキテクチャをカバーする車載メモリシステム
  • 産業用および民生用アプリケーションにわたるエッジコンピューティングとIoTメモリソリューション
  • マイクロコントローラ、SoC、先端半導体アプリケーション向けの組み込みメモリ分析

戦略的ビジネスインテリジェンス

  • 3Dスタッキングやチップレットアーキテクチャを含む高度なパッケージングおよび統合技術
  • 商用製品分析によるプロセッシング・イン・メモリおよびコンピューテーショナル・ストレージの開発
  • 技術ライフサイクルにわたる持続可能性と環境への影響評価
  • 過去のトレンドと将来予測モデルによる包括的な価格分析
  • 量子メモリやニューロモーフィックメモリを含む画期的な技術研究による2036年までの技術ロードマップ

企業インテリジェンスと市場ポジショニング:

  • 3D Plus、4DS Memory、Adata Technology、Advantest Corporation、AMD (Advanced Micro Devices)、Ambiq Micro、Amkor Technology、ANAFLASH、AP Memory、Apacer Technology、Applied Materials、ASE Group、ASM International、ASML Holding、Atomera、Avalanche Technology、Axelera AI、BeSang Inc、Besi(BE半導体)、Celestial AI、Cerebras Systems、Crocus Nanoelectronics、Crossbar Inc、CXMT (ChangXin Memory Technologies), d-Matrix, Dosilicon, eMemory, ESMT (Elite Semiconductor), Etron Technology, Everspin Technologies, Expedera, Ferroelectric Memory Company, Floadia Corporation, Fudan Microelectronics, Giantec Semiconductor, GigaDevice Semiconductor, GlobalFoundries, Google LLC, Graphcore, Groq, GSI Technology, Gwanak Analog Co.Ltd.、Hailo、Hefei Reliance Memory、HFC (Hefei Core Storage)、HHGrace、Hikstor、日立製作所、Houmo.ai、IBM Corporation、IMEC、Infineon Technologies、Innostar Semiconductor、Innovation Memory、Inston Inc、インテル コーポレーション、Intelligent Hardware Korea (IHWK)、Intelligent Memory、Intrinsic Semiconductor Technologies、ISSI (Integrated Silicon Solution)、JCET Group、JHICC (Jinhua Integrated Circuit)、JONSPIN Road、Kingston Technology、Kioxia Corporation、Kneron Inc、Lam Research、Longsys Electronics、LQUOM、Luminous Computing、Lyontek Inc.、Macronix International、Marvell Technology、Maxio Technology、MediaTek Inc.、Microchip Technology、Micron Technology、MonolithIC 3D、Montage Technology、Mythic、Nantero Inc、Nanya Technology, NEC Corporation, Neo Semiconductor, NetList Inc., Netsol, Neumonda, NeuroBlade, NGD Systems, NTT, Numem Inc., Numemory, Nuvoton Technology, Nvidia, Onto Innovation, and more......など
