この調査レポートは、過酷な環境下での光ファイバー構成部品と関連機器および部品市場を主要地域別に調査・予測しています。
米国の光ファイバー通信市場専門調査会社エレクトロニキャスト社は、過酷な環境での光ファイバーコンポーネントと関連デバイス/パーツに関する調査レポートをアップデートした。この調査レポートが調査対象とする特殊な環境下で使用される部品等は、特殊設計のパッケージングに使用されるようなもので、従来の、または市販の製品に比べると、非常に少量で使用されるものである。対応すべき環境はますます増えており、大きさや重さを削減したり、衝撃や振動などにも耐えられることが求められている。
米国の光ファイバー通信市場専門調査会社エレクトロニキャスト社によれば、過酷な環境での光ファイバーコンポーネント市場では、南北アメリカが2009年の世界の53％を占めて、消費金額3億2800万ドルでトップであった。2位は欧州で、3位はアジア太平洋地域である。しかし、2009-2019年には、欧州とアジア太平洋での急速な成長が見込まれる。
The environments encountered by the components included in this analysis and forecast often require custom designed packaging, with much smaller quantities required, compared to packaging of components for conventional/commercial applications. The environmental extremes that must be accommodated are greater, there often is a need for minimizing size and weight, shock and vibration environments
are more extreme.
According to ElectroniCast, the American region in 2009, led in global consumption of harsh environment fiber optic components with 53 percent relative market share ($328 million). The European region held second-place and the Asia Pacific occupied thirdplace. Over the 2009-2019 period, however, consumption of these components will expand faster in the European and the Asia Pacific regions.
Harsh Environment Defined Harsh Environment (HE) is defined, by ElectroniCast, as environment beyond the limits normally encountered by commercial telecom, datacom and commercial intra-equipment fiber data links; extremes of
- Temperature; above or below (-40 to +75) degrees C
- Shock and vibration
- Tensile strength (e.g., for fiber-guided missiles, tethered sensors, etc.)
- High electromagnetic or radio-frequency (EMI/RFI/EMP) interference
- Corrosive and/or solvent surroundings
- Atomic and other Radiation
- External pressure extremes
- Rough handling during installation/deployment
- Others
Necessary rough handling during installation or deployment also qualifies as a "harsh environment".
The 2009-2019 market forecast database is structured in a hierarchical format, with data groups at the lowest structural level, summing to a higher-level category for each significant fiber optic component and the supporting devices and parts, and by applications, as illustrated below. This market forecast data are segmented by region: Global Summary, America, Japan / China/Pacific Rim, and Europe.
